Steel Stud Drywall Ceiling System

Rondo Steel Studs can be used as a ceiling structure, where it’s difficult to install a suspended ceiling system.

Typical applications include corridors, bathrooms or open roof areas. In corridors, it’s often used to hide services such as air conditioning ducts, fire sprinkler pipework and electrical and data cabling.

By using the Rondo 51mm x 0.50bmt Steel Stud, along with the matching steel track on the walls you can span over 1800mm at 600mm centres for 10mm plasterboard lining. For 16mm plasterboard lining, it will span over 1700mm when spaced 600mm apart.

PRODUCT FEATURES

  • INTRODUCTION TO STEEL STUD DRYWALL CEILING SYSTEM

    You can download our Steel Stud Ceiling System Span Tables for details of single or continuous spans, and single or boxed studs. The span tables also show the minimum rows of bridging based on ceiling span and lining condition (lined one side). Bridging in a ceiling serves the same purpose as Noggings do in a stud wall.

    Rondo Steel Studs can also be used for ceiling bulkheads where a drop greater than 600mm makes it is hard to use our Furring Channels.

    To carry the additional layers of plasterboard and framing members, bulkheads require independent suspension. You can do this by, fixing the framing directly to the structural soffit or providing additional suspension hangers to the bulkhead.

    Not to mention, all bulkheads require bracing to provide lateral stability to the framework during incidental loading.

    In a nutshell, this means stud bracing needs to be fixed diagonally between the bulkhead framework and the structural soffit at regular intervals, or alternatively, by rigidly coupling the ceiling to the bulkhead.

    In fact, ceiling Friction Joints using Steel Stud allow for movement of building elements and Mechanical Joints are needed where the maximum spans of the ceiling exceed those allowable for Friction Joints, or where a more positive connection is required.

  • WHAT IS THE STEEL STUD DRYWALL CEILING SYSTEM SUITABLE FOR
    • Corridors
    • Bathrooms
    • Open Room Areas
    • Applications where it is difficult to install a suspended system
    • Fire-rated and non-fire rated areas
    • Seismic System by design
  • ADVANTAGES
    • Useful in areas where it is difficult to install a suspended ceiling system
    • Available in custom lengths
    • Manufactured with a minimum coating of Z275 for corrosion resistance
    • Profile widths range from 51 to 150mm, and gauges from 0.50 to 1.15bmt.

Resources

DESIGN MANUAL

Steel Stud Drywall Ceiling System

Click below for the Design Manual

Download

PRODUCT DATA SHEET

Steel Stud Drywall Ceiling System

Click below to download our Product Data Sheet:

Download

PROJECTS

Rondo Projects

Click below to view our projects:

VIEW RONDO PROJECTS

CAD FILES

(AU) Steel Stud Drywall Ceiling System CAD FILES

Assisting you with the design process, we’ve put together a library of DXF files for most of our products.

DOWNLOAD INDIVIDUAL CAD FILES
